型號

Model

12FA1224-25MP

12FA1624-25MP

12FA2524-25MP

12FA3524-25MP

12FA5024-25MP

焦距

Focal Length

12mm

16mm

25mm

35mm

50mm

像面尺寸(φ)

Image Size

φ19.3

φ19.3

φ19.3

φ19.3

φ19.3

像素尺寸(μm)

Pixel Size

2.74μm

2.74μm

2.74μm

2.74μm

2.74μm

光圈范圍(F數)

F-Number

F2.4-16

F2.4-16

F2.4-16

F2.4-16

F2.4-16

工作距離

Working Distance

100mm-∞

100mm-∞

150mm-∞

150mm-∞

250mm-∞

控制

Control

光圈

Iris

手動 Manual

手動 Manual

手動 Manual

手動 Manual

手動 Manual

聚焦

Focus

手動 Manual

手動 Manual

手動 Manual

手動 Manual

手動 Manual

最近物距視場范圍

Minimum Object Distance

FOV

-149.68 x -129.48

-105.17 x -90.98

-88.89 x -76.71

-63.65 x -55.06

-74.71 x -64.63

視場角(°)

Angle of View

1.2"

62.33x55.33x76.12

48.83x42.86x61.36

31.42x27.32x41.19

22.51x19.53x29.33

15.66x13.57x20.50

1.1"

54.5x54.5x71.6

42.12x42.12x57.24

27.58x27.58x38.32

19.1x19.1x26.76

13.28x13.28x18.76

1.0"

56.2x43.6x71.08

43.46x33.24x53.04

28.52x21.58x35.3

19.76x14.9x24.54

13.76x10.34x17.22

分辨率

Resolution

25MP

25MP

25MP

25MP

25MP

TV畸變

(最近物距至無窮遠最大畸變值)

Max TV Distortion

0.870

0.073

-0.106

-0.072

0.062

基準工作距離TV畸變

(200mm-400mm)%

Optimal TV Distortion

0.390

0.070

-0.040

0.015

0.011

接口

Mount

C

C

C

C

C

濾鏡尺寸

Filter Size

M40.5*0.5

M37*0.5

M40.5*0.5

M40.5*0.5

鏡頭尺寸

Dimension

φ50*66.96

φ42.5*59.76

φ40*58.44

φ42*59.32

φ42*61.16

重量

Weight

218.5

189.5

161.7

174

179

溫度范圍(°)

Operating Temperature

-10~+50℃

-10~+50℃

-10~+50℃

-10~+50℃

-10~+50℃
